Application
This machine is suitable for the automated production of granular materials such as broken tea, health tea, and traditional Chinese medicine formula tea.
Advantages
Independently developed PLC control to easily realize human-computer interaction and simple operation
The inner bag is heat-sealed filter tissue paper, which automatically completes the processes of hanging the thread and pasting the label.
The outer bag is a heat-sealed three-seal bag type, which automatically completes processes such as sealing, cutting, coding, and counting.
The inner and outer bags are formed at one time, and the inner bag conveying process is automatically completed by a pneumatic robot.
The exterior of the entire machine is made of 304 stainless steel, which complies with food and drug hygiene and safety.
Applicable packaging materials
PET/AL/PE (low temperature) PET/aluminized/PE (low temperature) paper/AL/PE (low temperature)
Packing material thickness <0.1mm, coil inner diameter 75mm, outer diameter <350mm
Technical Parameters
Packaging efficiency: 30-45 bags/minute
Inner bag size: length 50-60mm, width 30-80mm
Outer bag size: length 60-120mm, width 70-90mm
Label size: 20mm long and 17.5mm wide
Measuring range: 3-20ml
Power requirements: 220V 50HZ 3.5KW
Air source requirement: 0.6MPa 0.3L/min
Packing size: 900*610*1500mm 450kg
